简介

这里就一句话说明了哈，并能找到这里，都是知道这个是要干嘛的了。kaptcha 是谷歌开源的简单实用的验证码生成工具。

项目源码

项目工程源码路径，
spring-boot-demo/boot-captcha-kaptcha at main · Wayfreem/spring-boot-demo · GitHub
， 可以结合源码来看。

项目工程截图

项目搭建

第一步：引入依赖包

关于依赖啊，这里我要说明下，在我看有些博客上面说引入包的时候，说的另外的一个包地址，我就觉很奇怪，还特地去查了下。

maven仓库

在这里我们发现 com.github.penggle » kaptcha 有 75 个使用。但是点击进去之后发现这个居然有一个 Vulnerabilities(漏洞)

com.github.penggle

最后呢，我在ruoyi 框架的源码下面看到这个引用，并且这个没有显示 Vulnerabilities(漏洞)，那就用这个吧。

 <!-- kaptcha 依赖包 --> <dependency> <groupId>pro.fessional</groupId> <artifactId>kaptcha</artifactId> <version>2.3.3</version> </dependency>

pro.fessional

第二步：增加配置文件

这里增加配置文件是为了方便于切换验证码格式

 这个可以选择 math 或者 char captcha.type=char

第三步：增加配置类

Kaptcha 是支持两种方式的验证码一种是计算类的 配置文件设置为 math，一种就是常规的方式 配置文件设置为 char

@Configuration public class KaptchaConfig { @Bean(name = "captchaProducer") public DefaultKaptcha getKaptchaBean() { DefaultKaptcha defaultKaptcha = new DefaultKaptcha(); Properties properties = new Properties(); // 是否有边框 默认为true 我们可以自己设置yes，no properties.setProperty(KAPTCHA_BORDER, "yes"); // 验证码文本字符颜色 默认为Color.BLACK properties.setProperty(KAPTCHA_TEXTPRODUCER_FONT_COLOR, "black"); // 验证码图片宽度 默认为200 properties.setProperty(KAPTCHA_IMAGE_WIDTH, "160"); // 验证码图片高度 默认为50 properties.setProperty(KAPTCHA_IMAGE_HEIGHT, "60"); // 验证码文本字符大小 默认为40 properties.setProperty(KAPTCHA_TEXTPRODUCER_FONT_SIZE, "38"); // KAPTCHA_SESSION_KEY properties.setProperty(KAPTCHA_SESSION_CONFIG_KEY, "kaptchaCode"); // 验证码文本字符长度 默认为5 properties.setProperty(KAPTCHA_TEXTPRODUCER_CHAR_LENGTH, "4"); // 验证码文本字体样式 默认为new Font("Arial", 1, fontSize), new Font("Courier", 1, fontSize) properties.setProperty(KAPTCHA_TEXTPRODUCER_FONT_NAMES, "Arial,Courier"); // 图片样式 水纹com.google.code.kaptcha.impl.WaterRipple 鱼眼com.google.code.kaptcha.impl.FishEyeGimpy 阴影com.google.code.kaptcha.impl.ShadowGimpy properties.setProperty(KAPTCHA_OBSCURIFICATOR_IMPL, "com.google.code.kaptcha.impl.ShadowGimpy"); Config config = new Config(properties); defaultKaptcha.setConfig(config); return defaultKaptcha; } @Bean(name = "captchaProducerMath") public DefaultKaptcha getKaptchaBeanMath() { DefaultKaptcha defaultKaptcha = new DefaultKaptcha(); Properties properties = new Properties(); // 是否有边框 默认为true 我们可以自己设置yes，no properties.setProperty(KAPTCHA_BORDER, "yes"); // 边框颜色 默认为Color.BLACK properties.setProperty(KAPTCHA_BORDER_COLOR, "105,179,90"); // 验证码文本字符颜色 默认为Color.BLACK properties.setProperty(KAPTCHA_TEXTPRODUCER_FONT_COLOR, "blue"); // 验证码图片宽度 默认为200 properties.setProperty(KAPTCHA_IMAGE_WIDTH, "160"); // 验证码图片高度 默认为50 properties.setProperty(KAPTCHA_IMAGE_HEIGHT, "60"); // 验证码文本字符大小 默认为40 properties.setProperty(KAPTCHA_TEXTPRODUCER_FONT_SIZE, "35"); // KAPTCHA_SESSION_KEY properties.setProperty(KAPTCHA_SESSION_CONFIG_KEY, "kaptchaCodeMath"); // 验证码文本生成器 这里需要修改为自己的 KaptchaTextCreator 路径 properties.setProperty(KAPTCHA_TEXTPRODUCER_IMPL, "com.wq.kaptcha.config.KaptchaTextCreator"); // 验证码文本字符间距 默认为2 properties.setProperty(KAPTCHA_TEXTPRODUCER_CHAR_SPACE, "3"); // 验证码文本字符长度 默认为5 properties.setProperty(KAPTCHA_TEXTPRODUCER_CHAR_LENGTH, "6"); // 验证码文本字体样式 默认为new Font("Arial", 1, fontSize), new Font("Courier", 1, fontSize) properties.setProperty(KAPTCHA_TEXTPRODUCER_FONT_NAMES, "Arial,Courier"); // 验证码噪点颜色 默认为Color.BLACK properties.setProperty(KAPTCHA_NOISE_COLOR, "white"); // 干扰实现类 properties.setProperty(KAPTCHA_NOISE_IMPL, "com.google.code.kaptcha.impl.NoNoise"); // 图片样式 水纹 com.google.code.kaptcha.impl.WaterRipple 鱼眼 com.google.code.kaptcha.impl.FishEyeGimpy 阴影 com.google.code.kaptcha.impl.ShadowGimpy properties.setProperty(KAPTCHA_OBSCURIFICATOR_IMPL, "com.google.code.kaptcha.impl.ShadowGimpy"); Config config = new Config(properties); defaultKaptcha.setConfig(config); return defaultKaptcha; } }

第四步：增加验证码文本生成器

public class KaptchaTextCreator extends DefaultTextCreator { private static final String[] CNUMBERS = "0,1,2,3,4,5,6,7,8,9,10".split(","); @Override public String getText() { Integer result = 0; Random random = new Random(); int x = random.nextInt(10); int y = random.nextInt(10); StringBuilder suChinese = new StringBuilder(); int randomOperands = random.nextInt(3); if (randomOperands == 0) { result = x * y; suChinese.append(CNUMBERS[x]); suChinese.append("*"); suChinese.append(CNUMBERS[y]); } else if (randomOperands == 1) { if ((x != 0) && y % x == 0) { result = y / x; suChinese.append(CNUMBERS[y]); suChinese.append("/"); suChinese.append(CNUMBERS[x]); } else { result = x + y; suChinese.append(CNUMBERS[x]); suChinese.append("+"); suChinese.append(CNUMBERS[y]); } } else { if (x >= y) { result = x - y; suChinese.append(CNUMBERS[x]); suChinese.append("-"); suChinese.append(CNUMBERS[y]); } else { result = y - x; suChinese.append(CNUMBERS[y]); suChinese.append("-"); suChinese.append(CNUMBERS[x]); } } suChinese.append("=?@" + result); return suChinese.toString(); } }

第五步：增加获取验证码的工具类

@Component public class KaptchaUtil { @Value("${captcha.type}") private String captchaType; @Resource(name = "captchaProducer") private Producer captchaProducer; @Resource(name = "captchaProducerMath") private Producer captchaProducerMath; / * 获取验证码 * @return Map {"code": "进行验证的值", "img": "base64 格式的图片"} */ public Map getCaptcha() { // code 是我们需要验证的值，可以放到 缓存 中方便于验证 String capStr = null, code = null; BufferedImage image = null; if ("math".equals(captchaType)) { String capText = captchaProducerMath.createText(); capStr = capText.substring(0, capText.lastIndexOf("@")); code = capText.substring(capText.lastIndexOf("@") + 1); image = captchaProducerMath.createImage(capStr); } else if ("char".equals(captchaType)) { capStr = code = captchaProducer.createText(); image = captchaProducer.createImage(capStr); } // 转换流信息写出 FastByteArrayOutputStream os = new FastByteArrayOutputStream(); try { ImageIO.write(image, "jpg", os); } catch (IOException e) { throw new RuntimeException("获取验证码报错：" + e.getMessage()); } Map reslutMap = new HashMap(); reslutMap.put("code", code); reslutMap.put("img", Base64.encode(os.toByteArray())); return reslutMap; } }

另外说明一点，由于 Base64 在当前的这个 jdk 版本中没有了，所以我偷下懒直接复制了一份出来，具体直接见源码。

第六步：增加一个 controller 便于 http 调用

@RestController public class CaptchaController { @Autowired private KaptchaUtil kaptchaUtil; @GetMapping("getCaptchaImage") public Map getCode(HttpServletRequest request) { return kaptchaUtil.getCaptcha(); } }

测试访问

通过浏览器访问
http://localhost:8080/getCaptchaImage 会得到 base64 的值，然后将 base64 的值放入到
static\index.html 中的 img标签中，通过浏览器访问就好了

测试

放入到 html 中去测试

<!DOCTYPE html>
<html>
<head>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <title>`</title>
</head>
<body>


</body>
</html>

验证码图片：

验证码
